Ricoh Imaging | Pentax DA 70mm f/2.4 LTD HD Lens (Black)

High-grade HD coating for exceptional image rendition

The HD PENTAX-DA Limited interchangeable lenses are designed for use with K-mount lens-interchangeable digital cameras. These lenses inherit the distinctive visual description and a premium appearance of the acclaimed PENTAX Limited Lens series, while adding the state-of-the-art HD coating and a round-shaped diaphragm, to deliver even higher digital imaging performance in combination with a K-mount camera body.


New HD coating

This lens uses a new-generation multicoating that reduces the reflection rate in the visible spectrum up to 50% more than conventional multicoating. This enables the reduction of flare and ghosting for the shooting of clear, high-contrast images even under backlighting and other adverse conditions.


Round-shaped diaphragm for beautiful out-of-focus rendition

All lenses feature a completely round-shaped diaphragm to optimize the performance of their distinctive optics. This diaphragm produces a natural, beautiful bokeh (out-of-focus) effect, while minimizing the streaking effect of point light sources.


Premium quality of the Limited Lens-series

While inheriting the design concept of the Limited Lens series, these lenses were designed by combining a series of mechanical and numerical evaluations with human assessment of test-shooting samples to assure the ultimate in image reproduction. Their optical design has been optimized for digital photography to deliver sharp, clear images with outstanding contrast, even at the maximum aperture. In addition, their lens barrel, hood and cap are all made of a high-grade aluminum material, hand-machined for perfect proportions and beautiful texture.


Other Features

  • Equivalent to 107 mm in 35mm film format
  • Fast manual focusing in AF mode with Quick Shift focus system
  • Super Protect coating of the front lens element for effective protection against dirt and finger-marks
  • Aluminium Alloy


Angle Of View

23° (w/ Pentax DSLR)

Number Of Diaphragm Blades


Minimum Focusing Distance

27.5’ (2.3m)

Maximum Magnification



Without hood 4.6 oz (147g)

Objective Cap


Lens Aperture Ring


Diaphragm Control

Fully Automatic


Quick-shift Focus, SP (Super Protect) Coating

Lens Construction

6 elements in 5 groups



Minimum Aperture


Filter Diameter



2.5 x 1.0” (63.0 x 26mm)


Soft Lens Case


MH-RF49 (metal hood)

Tripod Adapter


Focal Length

70mm (equiv 107mm)

Whats in the box?

Lens Cap for DA 70mm Ltd (Black) OR Lens Cap for DA 70mm Ltd (Silver)
Rear Lens Cap B
Lens Hood MH-RF49 (Black) OR Lens Hood MH-RF49 (Silver)
Lens Soft Case for DA 70mm Ltd
